Primarily used for Geotechnical Investigations, Insitu Testing, Disturbed and Undisturbed Soil Samples, Overburden Drilling along with geotechnical Construction projects.
​Equipment Brief
-
Mud Rotary, Air Rotary, Wireline Coring BQ to PQ, Auger Drilling
-
Odex and Down Hole Hammer Drilling
-
Horizontal and Directional Drilling
-
Geotechnical Investigations, Insitu Testing Disturbed and Undisturbed soil Samples and Overburden Coring
-
Grouting, Anchors and Piling
-
Water Wells and Environmental Wells
-
Production Coring
Specifications
-
100 HP 575 Volt Electric Motor
-
Head Torque - 0 to 12,500 ft/lbs
-
Head RPM - 0 to 800
-
Head Travel - 7 or 12 feet
-
Pull Down Pressure - 37,600 lbs
-
Pullback Pressure - 50,000 lbs
-
Main Winch - 8,000 lbs
-
Auxiliary Winch - 5,000 lbs
-
Wireline Winch - 1,500 lbs
-
Vertical Mast Length - 26 or 31 feet
Rig Capacity
-
HQ Core to Depths of 3,000 feet
-
6” Mud Rotary to Depths of 1,500 feet
-
6” Odex Casing Systems to Depths of 250 feet
-
Hole Diameters - 2” to 14”
Capacities are contingent on ground conditions
|
|
-
Vertical Hydraulic Mast Slide - 48”
-
Hydraulic Rod Clamp Range - 2” to 12” Pipe
-
Dual Hydraulic Breakout Wrenches - 2” to 12” Pipe
-
Head Off Holes for Rod Tripping - 25 foot Lengths
-
Duplex Mud Pump - 200 gpm at 500 psi
-
Triplex Coring Pump - 30 gpm at 1,000 psi
|
